Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking

Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking
Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking
Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking

Imagem Grande :  Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking

Detalhes do produto:
Lugar de origem: CHINA
Marca: GNEE
Certificação: SGS
Condições de Pagamento e Envio:
Preço: negotiable
Detalhes da embalagem: Embalagem digna do mar, ou seja, bandeja de madeira ou aço com tira de aço, etc.
Tempo de entrega: 5-9 dias úteis
Termos de pagamento: Negociável
Contato

Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking

descrição
Destacar:

swage-locked steel bar grating

,

steel grating for walkways

,

platform grating with warranty

Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking
Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking 0
Our swage-locked steel bar grating has become the preferred choice for a diversity of applications, including industrial, architectural and construction, and municipal engineering applications, due to its high strength-to-weight ratio, minimum deflection and maximum safety.
Our swage locked steel grating is manufactured by a swaging and welding process. In this process, the cross bars are inserted into pre-punched holes (usually diamond-shaped holes or round holes) in the bearing bars and then welded at each intersection, thus forming a positive mechanical connection permanently.
As a rule, the cross bars are twisted square steel bars or round steel bars.
Product Specifications
Type of Bearing Bars Size of Bearing Bars (mm, Depth x Thickness) Size of Cross Bars (mm) Pitch of Rectangular Holes (mm)
Rectangular Flat Bars 25 × 2 8 x 8 30x100, 40x100, 60x100
25 × 3 8 x 8 30x100, 40x100, 60x100
25.4 × 4.76 8 x 8 30x100, 40x100, 60x100
30 × 5 8 x 8 30x100, 40x100, 60x100
32 × 3 8 x 8 30x100, 40x100, 60x100
32 × 5 8 x 8 30x100, 40x100, 60x100
38 × 3 8 x 8 30x100, 40x100, 60x100
38 × 5 8 x 8 30x100, 40x100, 60x100
40 × 3 8 x 8 30x100, 40x100, 60x100
40 × 4 8 x 8 30x100, 40x100, 60x100
40 × 5 8 x 8 30x100, 40x100, 60x100
40 × 12 8 x 8 30x100, 40x100, 60x100
45 × 3 8 x 8 30x100, 40x100, 60x100
45 × 5 8 x 8 30x100, 40x100, 60x100
50 × 3 8 x 8 30x100, 40x100, 60x100
50 × 4.5 8 x 8 30x100, 40x100, 60x100
55 × 3 8 x 8 30x100, 40x100, 60x100
60 × 3 8 x 8 30x100, 40x100, 60x100
60 × 12 8 x 8 30x100, 40x100, 60x100
65 x 5 8 x 8 30x100, 40x100, 60x100
I-Shaped Steel Bars 26.8 × 6.25 8 x 8 30x100, 40x100, 60x100
25.4 × 6.35 8 x 8 30x100, 40x100, 60x100
65 × 6.35 8 x 8 30x100, 40x100, 60x100
50.8 × 6.35 8 x 8 30x100, 40x100, 60x100
T-Shaped Steel Bars 32 x 60 8 x 8 30x100, 40x100, 60x100
28 x 52 8 x 8 30x100, 40x100, 60x100
Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking 1
Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking 2
Type SL Swage-Locked Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking 3

etiqueta:

metal bar grating,

metal grate flooring,

steel grating platform
